Technical Data Sheets

Rico Products works with thousands of materials formulated specifically for demanding electronics applications. The data below represents a portion of the most common thermal management materials we convert for our customers. If you do not see data for the material you need, please contact our sales team for information and support.

Click any category to expand the table.

HENKEL (Bergquist® / Loctite® Thermal Interface Materials)

Part Number Thermal Conductivity
W/(m-K) 		Key Features Technical Data
Sheet
Sil Pad TSP 900 0.9 Silicone based, fiberglass reinforced Download
Sil Pad TSP K900 0.9 Silicone based, Kapton® reinforced, high dielectric strength Download
Sil Pad TSP PP900 0.9 Polyester based, fiberglass reinforced, high dielectric strength Download
Sil Pad TSP PPK900 0.9 Polyester based, Kapton® reinforced, high dielectric strength Download
Sil Pad TSP 1100ST 1.1 Silicone based, fiberglass reinforced, soft tack both sides Download
Sil Pad TSP K1100 1.1 Silicone based, Kapton® reinforced, high dielectric strength Download
Sil Pad TSP PP1200 1.2 Polyester based, fiberglass reinforced Download
Sil Pad TSP K1300 1.3 Silicone based, Kapton® reinforced, high dielectric strength Download
Sil Pad TSP PPK1300 1.3 Polyester based, Kapton® reinforced, high dielectric strength Download
Sil Pad TSP 1600 1.6 Silicone based, fiberglass reinforced, highly compliant Download
Sil Pad TSP 1600S 1.6 Silicone based, fiberglass reinforced, highly compliant Download
Sil Pad TSP 1800 1.8 Silicone based, fiberglass reinforced, non-tacky both sides Download
Sil Pad TSP 1800ST 1.8 Silicone based, fiberglass reinforced, soft tack both sides Download
Sil Pad TSP A2000 2.0 Silicone based, fiberglass reinforced, high mounting pressure Download
Sil Pad TSP Q2000 2.0 Silicone based, fiberglass reinforced, pre-solder/clean compatible Download
Sil Pad TSP Q2500 2.5 Silicone based, aluminum reinforced, pre-solder/clean compatible Download
Sil Pad TSP A3000 3.0 Silicone based, fiberglass reinforced Download
Sil Pad TSP 3500 3.5 Silicone based, fiberglass reinforced Download
Hi Flow THF 700FT 0.7 Phase change, aluminum reinforcement carrier Download
Hi Flow THF 900 0.7 Phase change, aluminum reinforcement carrier Download
Hi Flow THF 1000F-AC 1.0 Phase change, aluminum reinforcement carrier Download
Hi Flow THF 1000U 1.0 Non-reinforced, phase change, on release liner Download
Hi Flow THF 1400P 1.4 Phase change, polyimide reinforcement carrier Download
Hi Flow THF 1500P 1.5 Phase change, polyimide reinforcement carrier Download
Hi Flow THF 1600G 1.6 Phase change, fiberglass reinforcement carrier Download
Hi Flow THF 1600P 1.6 Phase change, polyimide reinforcement carrier Download
Hi Flow THF 3000UT 3.0 Non-reinforced, phase change, tabulated Download
Loctite EIF 1000 0.45 Phase change, Kapton® reinforcement carrier Download
Loctite TCF 1000 1.0 Phase change, aluminum reinforcement carrier Download
Bond Ply TBP 400B 0.4 Acrylic based, PEN reinforcement carrier Download
Bond Ply TBP 400P 0.4 Acrylic based, polyimide reinforcement carrier Download
Bond Ply TBP 720LMS 0.72 Silicone based, fiberglass reinforced, heat cured, laminating adhesive Download
Bond Ply TBP 800 0.8 Acrylic based, fiberglass reinforced, PSA tape Download
Bond Ply TBP 850 0.8 Acrylic based, fiberglass reinforced, PSA tape Download
Bond Ply TBP 1400 LMS HD 1.4 Silicone based, fiberglass reinforced, heat-cured, laminating adhesive Download
Gap Pad TGP 800VO 0.8 Silicone based, conformable, gap filling pad Download
Gap Pad TGP 800VOS 0.8 Silicone based, highly conformable, gap filling pad Download
Gap Pad TGP 1100SF 0.9 Silicone-free, gap filling pad Download
Gap Pad TGP 1000HD 1.0 Silicone based, conformable, gap filling pad Download
Gap Pad TGP 1000VOUS 1.0 Silicone base, ultra conformable, gap filling pad Download
Gap Pad TGP 1000VOUSB 1.0 Silicone based, ultra conformable, vibration dampening, gap filling pad Download
Gap Pad TGP EMI 1000 1.0 Silicone based, conformable, EMI absorbing, gap filling pad Download
Gap Pad TGP HC1000 1.0 Silicone based, highly conformable, gel-like modulus, gap filling pad Download
Gap Pad TGP 1300 1.3 Silicone based, highly conformable, inherent tack both sides, gap filling pad Download
Gap Pad TGP 1500R 1.5 Silicone based, fiberglass reinforced, conformable, gap filling pad Download
Gap Pad TGP 1500 1.5 Silicone based, non-reinforced, conformable, gap filling pad Download
Gap Pad TGP A2000 2.0 Silicone based, fiberglass reinforced, conformable, gap filling pad Download
Gap Pad TGP 2000 2.0 Silicone based, fiberglass reinforced, highly conformable, gap filling pad Download
Gap Pad TGP 2000SF 2.0 Silicone-free, fiberglass reinforced, conformable, gap filling pad Download
Gap Pad TGP 2202SF 2.0 Silicone-free, PET reinforcement carrier, gap filling pad Download
Gap Pad TGP 2400 2.4 Silicone based, fiberglass reinforced, highly conformable, gap filling pad Download
Gap Pad TGP A2600 2.6 Silicone based, fiberglass reinforced, gap filling pad Download
Gap Pad TGP 3000 3.0 Silicone based, fiberglass reinforced, highly conformable, gap filling pad Download
Gap Pad TGP 3000ULM 3.0 Silicone based, ultra conformable, ultra low moldulus, gap filling pad Download
Gap Pad TGP 3004SF 3.0 Silicone-free, PET reinforcement carrier, gap filling pad Download
Gap Pad TGP HC3000 3.0 Silicone based, fiberglass reinforced, highly compliant, gap filling pad Download
Gap Pad TGP 3500 ULM 3.5 Silicone based, ultra conformable, low modulus, gap filling pad Download
Gap Pad TGP 5000 5.0 Silicone based, fiberglass reinforced, conformable, gap filling pad Download
Gap Pad TGP HC5000 5.0 Silicone based, fiberglass reinforced, highly conformable, gap filling pad Download
Gap Pad TGP 6000ULM 6.0 Silicone based, fiberglass reinforced, ultra low modulus, highly conformable, gap filling pad Download
Gap Pad TGP 7000ULM 7.0 Silicone based, fiberglass reinforced, ultra low modulus, highly conformable, gap filling pad Download
Gap Pad TGP 10000ULM 10.0 Silicone based, extremely soft, ultra low modulus, gap filling pad Download
Gap Pad TGP 12000ULM 12.0 Silicone based, extremely soft, ultra low modulus, gap filling pad Download
Gap Filler TGF 1000 1.0 Silicone based, two-component, liquid gap filler Download
Gap Filler TGF 1000SR 1.0 Silicone based, two-component, slump resistant, liquid gap filler Download
Gap Filler TGF 1100SF 1.1 Silicone-free, two-component, liquid gap filler Download
Gap Filler TGF 1400SL 1.4 Silicone based, two-component, self-leveling, liquid gap filler Download
Gap Filler TGF 1450 1.5 Silicone based, two-component, optimized for dispensing, liquid gap filler Download
Gap Filler TGF 1500 1.8 Silicone based, two-component, optimized for dispensing, liquid gap filler Download
Gap Filler TGF 1500LVO 1.8 Silicone based, two-component, low outgassing, liquid gap filler Download
Gap Filler TGF 2000 2.0 Silicone based, two-component, liquid gap filler Download
Gap Filler TGF 3010APS 3.0 Silicone-free, two-component, fast dispensing, liquid gap filler Download
Gap Filler TGF 3500LVO 3.5 Silicone based, two-component, low outgassing, liquid gap filler Download
Gap Filler TGF 3600 3.6 Silicone based, two-component, liquid gap filler Download
Gap Filler TGF 4000 4.0 Silicone based, two-component, liquid gap filler Download
Gap Filler TGF 4500CVO 4.5 Silicone based, two-component, low outgassing, fast dispensing, liquid gap filler Download
Liqui Bond TLB SA1000 1.0 Silicone based, one-component, liquid adhesive Download
Liqui Bond TLB EA1800 1.8 Epoxy based, two-component, dispensable, liquid adhesive Download
Liqui Bond TLB SA2005RT 2.0 Silicone based, two-component, liquid adhesive Download
Liqui Bond TLB SA3500 3.5 Silicone based, two-component, liquid adhesive Download
Liqui Form TLF LF2000 2.0 Silicone based, one-component, dispensable, liquid formable gel, no curing required Download
Liqui Form TLF LF3500 3.5 Silicone based, one-component, dispensable, liquid formable gel, no curing required Download
Liqui Form TLF LF3500CGEL 3.5 Silicone based, one-component, fast dispensing, curable, liquid formable gel Download
Liqui Form TLF 3800LVO 3.8 Silicone based, one-component, low outgassing, liquid formable gel, no curing required Download
Liqui Form TLF 4500CGEL SF 4.5 Silicone-free, one-component, curable, liquid formable gel Download
Liqui Form TLF 5800LVO 5.8 Silicone based, one-component, low outgassing, liquid formable gel, no curing required Download
Liqui Form TLF 6000HG 6.0 Silicone based, one-component, liquid formable gel, no curing required Download

FUCHS (Thermal Interface Materials)

Part Number Thermal Conductivity
W/(m-K) 		Key Features Technical Data
Sheet
FUCHS TIM EJC 741 1.0 Non-silicone, non-gritted Download
FUCHS TIM EJC 742 0.9 Non-silicone, non-gritted Download
FUCHS TIM EJC 744 0.5 Non-silicone, gritted / abrasive Download
FUCHS TIM EJC 745NS 0.8 Non-silicone, non-gritted Download
FUCHS TIM EJC 745SL 1.0 Silicone based, non-gritted Download
FUCHS TIM GREASE 410 0.8 Non-silicone, low viscosity, excellent wetting, thin bondline Download
FUCHS TIM GREASE 412 2.0 Non-silicone, no-slump, thin bondline, thixotropic Download
FUCHS TIM GREASE 430 3.0 Non-silicone, no-slump, thin bondline, thixotropic Download
FUCHS TIM GREASE 510 0.8 Non-reactive silicone, thin bondline, thixotropic Download
FUCHS TIM GREASE 510CR 1.0 Silicone based, no-drip, thin bondline, thixotropic Download
FUCHS TIM GREASE 510FG 1.0 Non-reactive silicone, FDA approved for use in and around food processing Download
FUCHS TIM GREASE 515 2.0 Ceramic based, non-reactive, non-abrasive, designed for optics applications Download
FUCHS TIM GREASE 516 0.8 Non-reactive silicone, reworkable, thin bondline Download
FUCHS TIM GREASE 519 1.3 Non-reactive silicone, no-sag/no-drip, thin bondline, thixotropic Download
FUCHS TIM GREASE 610 1.0 Non-silicone, NSF H1 approved food-grade grease for continuous temperatures above 200°C Download
FUCHS TIM GREASE 611 0.8 Non-silicone, NASA outgassing compliant, continuous-use temperatures above 200°C Download
FUCHS TIM GREASE 611HTC 3.2 Non-silicone, high temperature stable, low outgassing, reworkable, thin bondline Download
FUCHS TIM GREASE 611LV 0.8 Non-silicone, high temperature stable, low outgassing, reworkable Download
FUCHS TIM GREASE 613 1.2 Silicone based, high temperature stable, low outgassing, reworkable, dispensable Download
FUCHS TIM GREASE 614 2.2 High temperature stable, thixotropic, low outgassing, dispensable Download
FUCHS TIM GREASE 615 0.9 Non-silicone, high temperature stable, thixotropic, dispensable, low-cost solution Download
FUCHS TIM GREASE 1104 2.4 Non-silicone, low coefficient of friction for superior lubrication, low bleed and evaporation Download
FUCHS TIM GREASE 4060 6.0 Non-silicone, dispensable, screen printable, low outgassing, pump-out resistant Download
FUCHS TIM GREASE 4100 2.6 Non-silicone, dispensable, screen printable, thin bondline, pump-out resistant Download
FUCHS TIM GREASE 4200 3.2 Non-silicone, tacky, thixotropic, low outgassing, pump-out resistant Download
FUCHS TIM GREASE 5100 2.6 Silicone based, thin bondline, tacky, thixotropic, excellent wetting Download
FUCHS TIM LGF 2020NS 2.0 Non-silicone, two-part liquid gap filler, good compression set, low assembly stress Download
FUCHS TIM LGF 2021NS 2.0 Non-silicone, two-part liquid gap filler, good compression set, low assembly stress Download
FUCHS TIM PUTTY 3W 3.5 Non-silicone, dispensable, one-part gel/putty, no-cure, ultra soft Download
FUCHS TIM PUTTY 6W 6.0 Non-silicone, dispensable, one-part gel/putty, no-cure, soft and compliant Download
FUCHS TIM PUTTY 45 4.5 Non-silicone, dispensable, one-part putty, no-cure, soft and compliant Download
FUCHS TIM PUTTY 51W 5.1 Non-silicone, dispensable, one-part putty, no-cure, soft and compliant Download
FUCHS TIM PUTTY 61W 6.1 Non-silicone, dispensable, one-part putty, no-cure, soft and compliant, high dielectric strength Download
FUCHS TIM PUTTY 418 2.0 Non-silicone, dispensable, one-part putty, soft and compliant, reworkable, cost-effective solution Download

H.B. Fuller (Thermal Management Materials)

Part Number Thermal Conductivity
W/(m-K) 		Key Features Technical Data
Sheet
FLEXOBOND 442 BLACK 6.0 Urethane based resin system, high flexibility, low outgassing Download
EV THERM 441 1.0 Acrylic based, two-part, flame retardant, structural adhesive Download
HB FULLER 2532 0.8 Silicone based, two-part, fast cure, potting/sealant Download
EV PROTECT 5006 0.06 Flame retardant, ultra-lightweight, encapsulating foam Download
EV THERM 601 1.8 Acrylic/Acrylate based, one-part, flame retardant, sprayable coating Download
EV THERM 602 1.0 Acrylic/Acrylate based, two-part, flame retardant, coating Download

KERAFOL (Thermal Management Materials)

Part Number Thermal Conductivity
W/(m-K) 		Key Features Technical Data
Sheet
GFL 3020 1.8 Silicone based, two-component, soft and elastic, RT curing, flame retardant Download
GFL 3020 RF 2.0 Silicone based, two-component, soft and elastic, RT curing Download
GFL 3030 3.0 Silicone based, two-component, highly thixotropic, RT curing Download
GFL 3035 ULTRACOLD 3.5 Silicone based, two-component, operating range starting at -90°C, highly thixotropic, RT curing Download
GFL 3040 4.3 Silicone based, two-component, highly thixotropic, RT curing Download
GFL 3055 5.5 Silicone based, two-component, highly thixotropic, high dielectric strength, RT curing Download
GFL 1800 SL 1.8 Silicone based, two-component, low viscosity, RT curing, suitable for encapsulation Download
GFL 2400 SL 2.4 Silicone based, two-component, self-leveling, thin potting and encapsulation compound Contact Us
GFL 3000 SL 2.8 Silicone based, two-component, low viscosity, RT curing, suitable for encapsulation Download
GFU 15 1.5 Silicone-free, two-component, RT curing, contains no diisocyanate Download
86/125 SOFTTHERM 1.5 Silicone based, soft, high compressibility, single layer, fiberglass reinforced Download
86/128 SOFTTHERM 1.5 Silicone based, soft, high compressibility, double layer carrier film Download
86/225 SOFTTHERM 2.0 Silicone based, single layer, fiberglass reinforced, very soft Download
86/228 SOFTTHERM 2.0 Silicone based, double layer carrier film, very soft Download
86/235 SOFTTHERM 2.0 Silicone based, very soft, elastic, single layer, fiberglass reinforced Download
86/238 SOFTTHERM 2.0 Silicone based, very soft, elastic behavior, double layer carrier film Download
86/320 SOFTTHERM 2.5 Silicone based, very soft, elastic behavior, single layer, fiberglass reinforced Download
86/325 SOFTTHERM 3.0 Silicone based, very soft, elastic behavior, single layer, fiberglass reinforced Download
POLARIS 3000 SOFTTHERM 3.0 Silicone based, extreme temperature stable, suitable for military and aerospace Download
3500 SOFTTHERM 3.5 Silicone based, soft, elastic behavior, single layer Download
86/450 SOFTTHERM 4.5 Silicone based, elastic behavior, single layer Download
86/525 SOFTTHERM 5.5 Silicone based, plastic behavior, non-sticky with adhesive coating Download
6000 SOFTTHERM 6.0 Silicone based, elastic behavior, high thermal conductivity Download
U110 SOFTTHERM 2.0 Silicone-free, elastic behavior, highly electrically insulating Download
KP 97 KERATHERM Grease 5.0 Silicone based, ceramic filled, single component, non-crosslinking, very low bond line thickness Download
KP 98 KERATHERM Grease 6.0 Silicone based, ceramic filled, single component, non-crosslinking, very low bond line thickness Download
KP 99 KERATHERM Grease 9.2 Silicone based, ceramic filled, single component, non-crosslinking, very low bond line thickness Download
KP 12 KERATHERM Grease 10.0 Silicone-free, ceramic filled, non-crosslinking, very low bond line thickness Download
KP 14 KERATHERM Grease 10.0 Silicone-free, ceramic filled, non-crosslinking, very low bond line thickness Download
KL 95 KERATHERM 1.3 Acrylic-based, double-sided adhesive film, high bond strength, good adhesion to various surfaces Download
KL 91 KERATHERM 1.35 Acrylate-based, double-sided adhesive film, high bond strength, good adhesion to various surfaces Download
KL 90 KERATHERM 1.4 Acrylate-based, double-sided adhesive film, high bond strength, good adhesion to various surfaces Download
KERATHERM BOND 100 RT 1.5 Two-component, thixotropic, very soft, high bond strength, liquid thermal adhesive Download
PCM 16125C KERATHERM > 3.5 Improves surface contact, designed for screen or stencil printing, very low bond line thickness Download
KERASORB 1500 1.5 High EMI suppression at frequencies up to 77GHz, high electrical isolation, elastic behavior Download
KERASORB 2500 2.5 High EMI suppression at frequencies up to 77GHz, high electrical isolation, elastic behavior Download
S900 KERATHERM 7.5 Heat spreading graphite film, electrically conductive, high temperature stable, available with adhesive coating Download
KERAMOLD 15 1.5 Good thermal conductivity, electrically insulating, suitable for overmolding Download
KERAMOLD 20 2.0 Good thermal conductivity, electrically insulating, soft and elastic, suitable for overmolding Download
KERAMOLD 20N 2.0 Good thermal conductivity, high temperature stable, soft and elastic, suitable for overmolding Download
KERAMOLD 25 2.5 Good thermal conductivity, electrically insulating, firm and flexible support, suitable for overmolding Download

KISLING (Thermal Management Materials)

Part Number Thermal Conductivity
W/(m-K) 		Key Features Technical Data
Sheet
8702N 2.0 Silicone-free, single-component, heat-conducting paste Download
7501 Resin + 7920 Hardener 1.2 Epoxy based, electrically insulating, high chemical resistance Download
7600 Resin + 7920 Hardener 0.8 Epoxy based, electrically insulating, high chemical resistance Contact Us
7600 Resin + 7921 Hardener 0.8 Epoxy based, electrically insulating, high glass transition temperature, high chemical resistance Download
8503 Resin + 8901 Hardener 1.5 Polyurethane based, electrically insulating, excellent adhesion Download
8610 Resin + 8901 Hardener 0.6 Polyurethane based, electrically insulating, excellent adhesion, high temperature stable Download
8612 Resin + 8901 Hardener 0.6 Polyurethane based, electrically insulating, excellent adhesion, self-extinguishing properties Download
8612C Resin + 8930 Hardener 0.6 Polyurethane based, hard curing degree, electrically insulating, self-extinguishing properties Download
8615 Resin + 8901 Hardener 0.3 Polyurethane based, hard curing degree, highly electrically insulating, excellent adhesion Download
8617 Resin + 8973 Hardener 0.5 Polyurethane based, hard curing degree, electrically insulating, shock resistant properties Download
8800 Resin + 8930 Hardener 0.2 Polyurethane based, crystal clear, UV-resistant, soft curing degree, excellent adhesion Download
8807 Resin + 8930 Hardener 0.2 Polyurethane based, opaque or translucent depending on thickness, semi-hard curing degree Download
8808 Resin + 8930 Hardener 0.2 Polyurethane based, crystal clear, UV-resistant, medium hardness, excellent adhesion Download
8812 Resin + 8930 Hardener 0.2 Polyurethane based, crystal clear, UV-resistant, hard curing degree, excellent adhesion Download
8792 Resin + 8992 Hardener 2.0 Polyurethane based, electrically insulating, ideal for battery systems and power electronics Download

SHIN ETSU (Thermally Conductive Silicone Solutions)

Part Number Thermal Conductivity
W/(m-K) 		Key Features Technical Data
Sheet
EMI-TC803 2.5 EMI suppression, soft, flexible, thermal pad material Download
TC-11KI 1.6 High hardness, polyimide reinforced, thin film thermal pad, electrically insulating Download
TC-15TCI 0.6 High hardness, polyimide reinforced, thin film thermal pad, electrically insulating Download
TC-15TCP 0.6 High hardness, PEN reinforced, thin film thermal pad, electrically insulating Download
TC-A Series 0.8 High hardness, durable thermal pads, various thicknesses available Download
TC-BG Series 7.3 High hardness, fiberglass reinforced, thermal pad, various thicknesses available Download
TC-CAB-10 Series 2.3 Ultra-soft thermal pads, compressible, low assembly stress, various thicknesses available Download
TC-CAD-10 Series 3.2 Ultra-soft thermal pads, low assembly stress, excellent electrical insulation, various thicknesses available Download
TC-CAT-20 Series 4.5 Soft thermally conductive pads, excellent electrical insulation, available in multiple thicknesses Download
TC-CG Series 1.7 Thermal pads with fiberglass reinforcement for strength and hardness, various thicknesses available Download
TC-EG Series 3.1 Thermal pads with fiberglass reinforcement for strength and hardness, various thicknesses available Download
TC-FORS-2 Series 1.9 Soft thermal pads, high fuel and oil resistance, excellent electrical insulation Download
TC-PEN3-10 Series 3.2 Ultra-soft thermal pads, reduced density for weight reduction, various thicknesses available Download
TC PEN5-20 Series 5.2 Ultra-soft thermal pads, reduced density for weight reduction, various thicknesses available Download
TC-SET4-20 4.5 Soft thermal pad, low compression set, excellent adhesion, wide usage temperature range Download
TC-SP-1.7 Series 1.5 Ultra-soft, compressible, thermal pads, excellent electrical insulation, various thicknesses available Download
TC-SPA-3.0 Series 0.42 Ultra-soft thermal pads, non-electrically insulating, various thicknesses available Download
TC-TA-1 Series 1.1 Thermal pads, medium hardness, durable, excellent electrical properties, various thicknesses available Download
TC-TAG-2 Series 1.8 Thermal pads, fiberglass reinforced for strength and durability, various thicknesses available Download
TC-TAG-2-AA Series 1.8 Thermal pads, adhesive layer on one side, durable, various thicknesses available Download
TC-TAG-3 Series 3.4 Thermal pads, fiberglass reinforced for strength and durability, various thicknesses available Download
TC-TAG-3-AA Series 3.4 Thermal pads, adhesive layer on one side, durable, various thicknesses available Download
TC-TAG-8 Series 8.0 Thermal pads, fiberglass reinforced, durable, various thicknesses available Download
TC-TAP-2 Series 1.8 Thermal pads, polyimide reinforced for strength and hardness, excellent electrical properties Download
TC-TAP-2-HP Series 1.8 Thermal pads, polyimide reinforced for strength and hardness, high heat resistance Download
TC-THE Series 2.5 Soft thermal pads, compressible, excellent electrical insulation, various thicknesses available Download
TC-THS Series 2.5 Soft thermal pads, composite reinforced, electrically insulating, various thicknesses available Download
TC-TXE Series 3.3 Soft thermal pads, composite reinforced, electrically insulating, various thicknesses available Download
TC-TXS Series 3.3 Medium soft thermal pads, electrically insulating, various thicknesses available Download
TC-UP8A 8.0 Ultra-soft thermal pads, electrically insulating, long-term reliability, various thicknesses available Download
CLG-1500 1.5 Liquid, dispensable, gap filler, pre-cured single-component, resistant to pump-out Download
CLG-2500 2.9 Liquid, dispensable, gap filler, pre-cured single-component, resistant to pump-out Download
CLG-3500 3.5 Liquid, dispensable, gap filler, pre-cured single-component, resistant to pump-out Download
CLG-4500 4.8 Liquid, dispensable, gap filler, pre-cured single-component, resistant to pump-out Download
G-1000 2.4 Liquid, dispensable, gap filler, curable, pump-out and sag resistant, natural tackiness, reworkable Download
G-781 2.6 Liquid, dispensable, gap filler, heat cure, natural tackiness, reworkable Download
GUV-300 3.1 Liquid, dispensable, gap filler, single-component, UV-curable, natural tackiness, reworkable Download
GUV-500 5.1 Liquid, dispensable, gap filler, single-component, UV-curable, natural tackiness, reworkable Download
KE-4967 1.1 Liquid, dispensable, single-component, gap filling rubber, room-temperature cure, reworkable Download
SDP-1030 A/B 1.1 Liquid, dispensable, two-component, gap filler, heat or room-temperature cure, reworkable Download
SDP-2060 A/B 2.3 Liquid, dispensable, two-component, gap filler, heat or room-temperature cure, reworkable Download
SDP 5040 A/B 5.1 Liquid, dispensable, two-component, gap filler, heat or room-temperature cure, reworkable Download
SDP-6560 A/B 6.5 Liquid, dispensable, two-component, gap filler, heat or room-temperature cure, reworkable Download
X-23-8032 3.0 Liquid, dispensable, gap filler, heat cure, natural tackiness, reworkable Download
X-23-8038 4.0 Liquid, dispensable, gap filler, heat cure, natural tackiness, reworkable Download
KE-1184 A/B 2.0 Liquid, dispensable, electrically insulating, thermal adhesive, two-component, heat cure Download
KE-1861 A/B 0.83 Liquid, dispensable, two-component, thermal adhesive, heat cure Download
KE-1862 0.8 Liquid, dispensable, single-component, thermal adhesive, heat cure Download
KE-1867 2.0 Liquid, dispensable, single-component, thermal adhesive, heat cure Download
KE-1891 4.0 Liquid, dispensable, single-component, thermal adhesive, thixotropic, heat cure Download
KE-1897 A/B 1.6 Liquid, dispensable, two-component, thermal adhesive, heat cure Download
KE-1898 A/B 2.2 Liquid, dispensable, two-component, thermal adhesive, heat cure Download
KE-3467 2.4 Liquid, dispensable, single-component, thermal adhesive, room-temperature cure, low odor Download
KE-4916 0.82 Liquid, dispensable, single-component, thermal adhesive, room-temperature cure, low odor Download
KE-4918 0.88 Liquid, dispensable, single-component, thermal adhesive, fast, room-temperature cure Download
KE-4961 1.6 Liquid, dispensable, single-component, thermal adhesive, fast, room-temperature cure Download
KE-4962 2.5 Liquid, dispensable, single-component, thermal adhesive, fast, room-temperature cure Download
PCS-CR-10 2.0 Phase change material, electrically insulating, excellent pump-out resistance, high tackiness Download
PCS-LT-30 3.0 Phase change material, high tackiness, excellent pump-out resistance Download
PCS-PL-30 1.7 Phase change material, high tackiness, excellent pump-out resistance Download
G-747 0.9 Thermal grease, water repellent, oxidative stability Download
G-750 3.5 Thermal grease, general purpose, excellent dielectric strength, water repellent Download
G-751 4.5 Thermal grease, general purpose, electrically insulating, cold resistance Download
G-775 3.6 Thermal grease, high viscosity, resistant to pump-out, creep, and oil separation Download
G-776 1.3 Thermal grease, designed for high reliability and ease of use Download
G-777 3.3 Thermal grease, all-purpose, high reliability Download
G-779 3.0 Thermal grease, all-purpose, high reliability, for low bond line thickness applications Download
G-781 2.6 Thermal grease, high natural tackiness, superior reworkability Download
KS-609 0.73 Thermal grease, general purpose, superior electrical properties, water repellent, oxidative stability Download
KS-613 0.8 Thermal grease, superior electrical properties, water repellent, oxidative stability Download
OSR-500 3.1 Thermal grease, solvent diluted for ease of use Download
OSR-603 6.0 Thermal grease, not electrically insulating, high thermal conductivity, solvent diluted for ease of use Download
X-23-7868-2D 6.2 Thermal grease, solvent diluted for ease of use, exceptional thermal conductivity Download
X-23-7921-5 6.0 General purpose thermal grease, non-electrically insulating, cold resistance, water repellent Download
X-23-8033-1 4.0 Thermal grease, solvent diluted for ease of use Download
X-23-8052 6.0 General purpose thermal grease, electrically insulating, cold resistance, water repellent Download
X-23-8057 7.0 General purpose thermal grease, electrically insulating, cold resistance, water repellent Download
TC-SAS-T 0.7 Double-sided thermal tape, electrically insulating, excellent adhesion, wide usage temperature range, various thicknesses available Download

Need data for a material not listed?
